Type B, length 2, 16 IN (female/send)
Width: 117 mm, height: 79 mm, length: 252 mm
Supplied as assembled set comprising of all hardware parts including plates, profiles, strain relief, end pieces and screws. Labels for channel numbering not included.
Product | |
Title | NSB2B-16/0 |
Electrical | |
Contact resistance | < 5 mΩ |
Dielectric strength | 0.5 kVdc |
Insulation resistance | ≥ 1 GΩ |
Rated current per contact | 2 A |
Mechanical | |
Cable O.D. | 13 - 18 mm multicore |
Insertion force | ≤ 10 N |
Withdrawal force | ≥ 10 N |
Lifetime | > 1000 mating cycles |
Wiresize | 0.22 and 0.14 mm² |
Wiresize | 24 and 26 AWG |
Material | |
Shell | Aluminium |
Quad plates | POM |
End pieces | Thermoplastic |
Environmental | |
Temperature range | -25 °C to +70 °C |
